彩钢板净化装修型材及连接说明举例

彩钢板净化装修型材及连接说明举例

天物彩板集团专注彩涂卷行业17年——彩钢板净化装修型材_彩涂板卷价格走势图_苏州天物集团彩板请拨打网站上方电话免费咨询

1、50mm厚单面石膏岩棉手工板,两侧0.6mm厚彩钢板,石膏板厚度9.5mm,岩棉120kg/m3;墙板龙骨0.7镀锌板;全板厚度:50mm,双面涂膜,壁板连接方式为凹凸连接,耐火极限为≥ 60分钟。

webwxgetmsgimg
2、50mm厚单面石膏岩棉手工板,两侧0.6mm厚彩钢板,石膏板厚度9.5mm,岩棉120kg/m3;顶板龙骨为1.0镀锌板,全板厚度50mm,一面涂膜,顶板连接方式为企口连接,耐火极限为≥ 60分钟。
3、洁净门采用50铝合金平框钢板喷塑洁净门。门框和门边为铝合金平框,与50色板齐平,无台阶。铝合金厚度为1.5-2mm。门板为50纸蜂窝夹芯门板,两侧0.7镀锌板喷塑,不锈钢防火锁;
4.双层洁净平窗要求:
a、 玻璃四周倒角,玻璃光滑,无快速开启;
b、 在玻璃周围涂上黑色边缘,以覆盖玻璃和铝框之间的双面胶带;
c、 将干燥剂放入窗框中。窗户完工后,在框架和玻璃之间的连接处周围进行粘合和密封,以防止湿气进入冷凝液;
d、 安装时将中国铝材插入板与窗之间;

1. 50mm thick single-sided gypsum rock wool manual board, 0.6mm thick color steel plate on both sides, gypsum board thickness of 9.5mm, 120kg / m3 rock wool; Wall panel keel 0.7 galvanized sheet; The whole plate thickness: 50mm, double-sided film coating, the wall plate connection mode is concave convex connection, and the fire resistance limit is ≥ 60min.

2. 50mm thick single-sided gypsum rock wool manual board, 0.6mm thick color steel plate on both sides, gypsum board thickness of 9.5mm, 120kg / m3 rock wool; The keel of the top plate is 1.0 galvanized plate, the thickness of the whole plate is 50mm, one side is coated with film, the connection mode of the top plate is tongue and groove connection, and the fire resistance limit is ≥ 60min.
3. The clean door adopts 50 aluminum alloy flat frame steel plate plastic spraying clean door. The door frame and door edging are aluminum alloy flat frame flush with 50 color plate without steps. The aluminum alloy thickness is 1.5-2mm. The door plate is 50 paper honeycomb sandwich door plate, plastic spraying of 0.7 galvanized plate on both sides, and stainless steel fireproof lock;
4. Requirements for double-layer clean flat window:
a. Chamfer around the glass, and the glass is smooth without quick opening;
b. Paint black edges around the glass to cover the double-sided tape between the glass and the aluminum frame;
c. Put desiccant into the window frame. After the window is finished, glue and seal around the connection between the frame and the glass to prevent moisture from entering the condensation;
d. Insert Chinese aluminum between the plate and the window during installation;
