彩涂板房屋施工中必知的注意事项

彩涂板房屋施工中必知的注意事项

彩涂板作为一种新型的原材料,具有重量轻、外形美观、防腐性能好等优点,具有以钢代木、建筑高效、节能、防污染等优点。在今天的建筑物中,它经常被用来建造建筑物。那么彩涂板房在施工中有哪些注意事项,需要大家了解?

webwxgetmsgimg (1)
1、安装吊顶板:顶板的重量支撑是通过垂直板固定的,T形铝板悬挂在中间。长边缝用固定嵌件固定加固,短边缝用T型铝及连接板抽芯铆钉固定。平屋顶应平整,板缝应密实、均匀、光滑、无痕迹、无损伤。注意垂直墙板。
2.彩涂板包装柱、箱、内外R角
净化区柱用б= 50彩涂板可节省材料,统一50内外R角,先将不锈钢门窗框装入门窗洞口,固定牢固,注意门的开启方向,安装窗玻璃。闭门器应调整好开门速度和力度。一般关门时,前半部分速度快,后半部分扭矩小,速度慢,以减少关门时的冲击和噪音。
3.密封硅胶:在净化区,以下所有可能影响清洁度的缝隙均应涂上密封硅胶
彩涂板之间的拼接接头,R角与墙板和顶板之间的所有间隙;空调风道、出风口、高效过滤器与墙顶板之间的间隙;电通过墙板顶板保护管槽与孔边之间的缝隙;所有开关插座灯具与彩涂板顶面的间隙;全过程、给排水、保护管及孔洞清理;玻璃和框架之间的间隙。
在清洗彩色涂层房屋时,应仔细清洁垂直接缝上的保护膜,并暂时揭下,但不得将其去除。用很大的力很难均匀、紧凑地调整垂直接缝,否则槽中的碎屑和粘合液会使硬块凝固。

As a new type of raw material, color coated board has the advantages of light weight, beautiful appearance and good anti-corrosion performance, such as replacing wood with steel, efficient construction, energy saving and pollution prevention. In today's buildings, it is often used to make buildings. So what kind of precautions does the color coated plate house have in the construction, which needs to be understood by everyone?

1. Install ceiling board: the weight support of the roof is through the vertical board fixed around and T-shaped aluminum suspended in the middle. The long side seam is fixed and reinforced by fixed inserts, and the short side seam is fixed by T-shaped aluminum and connecting plate core pulling rivet. The flat roof shall be flat, and the plate joints shall be dense, uniform, smooth, traceless and undamaged. Attention should be paid to the vertical wall panel.
2. Color coated board packing column, box, inner and outer R angle
For columns in purification area б= The 50 color coated board can save materials and unify the internal and external R angles of 50. First, install stainless steel door and window frames into the door and window openings, fix them firmly, pay attention to the opening direction of the door, and install the window glass. The door closer should adjust the opening speed and force well. Generally, when closing the door, the speed in the first half is fast, while the torque in the second half is small and the speed is slow, so as to reduce the impact and noise of closing the door.
3. Sealing silica gel: in the purification area, all the following gaps that may affect the cleanliness shall be coated with sealing silica gel
The splicing joints between the color coated boards, all the gaps between the R angle and the wallboard and the top plate; The gap between air duct, air outlet, high efficiency filter and wall top plate of air conditioner; The electricity passes through the gap between the protective pipe groove of the top plate of the wall panel and the edge of the hole; The gap between all switch socket lamps and the top surface of color coated plate; All process, water supply and drainage, protection pipe and hole clearance; The gap between glass and frame.
When cleaning the color coated houses, the protective film on the vertical joints should be carefully cleaned and temporarily uncovered, but never removed. It is very difficult to adjust the vertical joint evenly and compactly with a great force, otherwise, the debris in the groove and the adhesive liquid will solidify the hard block.
