彩涂夹芯板安装

彩涂夹芯板安装

(1)、材料进场洁净厂房构件应按施工进度计划要求,彩涂夹芯板运抵安装现场,轻搬轻放,避免划伤,并分类整齐堆放,严加保管。

(2)、测量放线严格对照施工图,现场测定轴线,标高尺寸,清理安装现场,准确放出大样。壁板安装前必须严格放线, 墙角应垂直交接, 防止累积误差造成


IMG_20191122_103011

壁板倾斜扭曲。壁板的垂直度偏差不大于0.2%。
(3)、材料检验洁净室构配件材料安装前,彩涂夹芯板严格检查其规格性能和完好程度,不合格或已损坏的构配件材料严禁安装。
(4)、彩涂夹芯板现场清理安装现场必须随时保持清洁,无积尘,并存施土过程中对零部件和场地随时清扫、擦净。
(5)、结构连接在施工安装时, 应首先进行吊件、铆固件等主主体结构和楼面、地面的连接件的固定。
(6)、施工操作
①、彩涂夹芯板按施工程序和金属壁板安装工艺节点具体要求进行施工。
②、地马槽与地坪的连接必须牢固,不得松动,用射钉间隔1 米左右将地马槽固定在地面上。装地马槽之间的垂直连接处应做好拼缝、拼角连接或预留出R球的位置。
③、壁板与壁板连接必须平整无凹凸,缝隙均匀,注胶平整光滑。安装时要用吊线锤控制壁板的垂直度, 安装好的板材做好彼此之间的定, 以防止壁板整体倾斜。
④、安装过程中不得撕下壁板表面塑料保护膜,禁止撞击和踩踏板面。
⑤、壁板上固定密闭窗,窗框四角铝合金处理合缝、平整,并且在玻璃安装之后用橡皮条将玻璃压紧,甚至需将窗户上部和两边橡皮条带胶压实,以防震动,

橡皮条脱落。

⑥、过滤器送风口、回风口,在壁板生产时按照二次设计图留孔要求预留,避免施工现场开孔,对壁板结构的破坏。
⑦、根据设计要求, 洁净区内壁板与顶板相接形成的各个阴阳角均采用铝合金圆弧型连接,回风口要设置可拆过滤网。
⑧、密封胶应平直光滑,不应有间断、外露、毛边等现象。
⑨、壁板安装同时要配合好电工,将接地扁铁与地面很好接触,以消除静电现象。
(7)、隐蔽验收在净化室安装的施工过程中必须随时清扫灰尘,对掩蔽空间的清扫应做好清扫记录。
(8)、成品保护加强成品保护教育,对已安装的成品或半成品严加保护,防止被污染及损坏。严格按顺序施工,做到衔接合理,避免返工,造成材料浪费、成品受损。

(9)、现场管理制定净化区域施工管理制度,控制人物流造成的区域污染。

(1) The materials entering the clean workshop should be transported to the installation site according to the construction schedule, and the color coated sandwich boards should be handled with care to avoid scratches. The components should be stacked in order and kept strictly.
(2) Measure and set out strictly according to the construction drawing, measure the axis, elevation and size on site, clean up the installation site, and accurately set out the detail drawing. Before the installation of the wallboard, the setting out must be strictly carried out, and the corners of the wallboard should be connected vertically to prevent the accumulation of errors
The panels are inclined and twisted. The perpendicularity deviation of the panel is not more than 0.2%.
(3) Before the installation of components and fittings in the clean room, the specification, performance and integrity of the color coated sandwich panel shall be strictly checked, and the unqualified or damaged components and fittings shall not be installed.
(4) The installation site must be kept clean at all times without dust accumulation, and the parts and site must be cleaned at all times during the soil application.
(5) During the construction and installation of structural connection, the main structure such as lifting parts, riveting parts, etc. shall be ixed with the connecting parts of floor and ground.
(6) Construction operation
① The color coated sandwich panel shall be constructed according to the construction procedure and the specific requirements of the metal panel installation process node.
② The connection between the ground manger and the floor must be firm and not loose, and the ground manger shall be fixed on the ground at an interval of about 1 m with shooting nails. The vertical connection between the floor mounted mangers shall be well jointed, corner jointed or reserved for r-ball.
③ The connection between the wallboard and the wallboard must be smooth without concave convex, the gap is even, and the glue injection is smooth. The perpendicularity of the wallboard shall be controlled by a plumb hammer during installation, and the installed boards shall be fixed with each other to prevent the overall inclination of the wallboard.
④ It is not allowed to tear off the plastic protective film on the surface of the wall panel during the installation process, and it is forbidden to impact and step on the pedal surface.
⑤ The closed window is fixed on the wall panel. The four corners of the window frame are treated with aluminum alloy to make the joint smooth. After the glass is installed, the rubber strip is used to compress the glass. Even the upper part and both sides of the window need to be compacted with rubber to prevent vibration,
The rubber strip fell off.
⑥ The air supply outlet and air return outlet of the filter shall be reserved according to the hole reservation requirements of the secondary design drawing during the production of the wall panel, so as to avoid the damage to the wall panel structure caused by the opening at the construction site.
⑦ According to the design requirements, the internal and external corners formed by the connection of the wall panel and the top plate in the clean area are all connected by aluminum alloy arc, and the air return outlet shall be equipped with detachable filter screen.
⑧ The sealant shall be straight and smooth without interruption, exposure, burr, etc.
⑨ At the same time, the installation of the wall plate should cooperate with the electrician to make the grounding flat iron in good contact with the ground, so as to eliminate the electrostatic phenomenon.
(7) The dust must be cleaned at any time during the construction process of the cleaning room installation, and the cleaning record of the masking space should be made.
(8) Finished product protection strengthen finished product protection education, and strictly protect the installed finished products or semi-finished products to prevent pollution and damage. The construction shall be carried out in strict accordance with the sequence, and the connection shall be reasonable to avoid rework, resulting in waste of materials and damage to finished products.
(9) On site management, the construction management system of purification area shall be formulated to control the regional pollution caused by human flow.
