镀铝锌彩钢板厂家讲镀锌板、彩涂板使用原则

镀铝锌彩钢板厂家讲镀锌板、彩涂板使用原则

天物彩板彩钢板安装加工配送一站式服务——更多汽车镀锌板厂家_北京镀铝锌彩钢板哪家好_天物彩板请拨打网站上方电话咨询

汽车镀锌板厂家_北京镀铝锌彩钢板哪家好_天物彩板

一镀锌板、彩涂板连接:采用拼装式EPS承插彩钢保温板,墙板厚度为50mm,外层为彩涂板,中间填充EPS保温材料,聚氨酯发泡连续成型,内外板及保温材料整体压制成型所有墙板均采用50mm厚EPS夹心彩钢板,顶板采用彩钢保温板拼装镀锌板房外径设计为(长×宽×高)mm:7000×4000×3150,设备内径设计为(长×宽×高)mm:6900×3900×2600在房间前端设置一套闸门,闸门尺寸(宽×高)mm:2800×2500房间侧设一组闸门一组安全门,尺寸(宽×高)mm:750×1800,材质同侧板,安全门设有压力保护装置,保证使用安全当室内压力过大时,安全门会自动打开并释放压力,并可进行疏散和通过在门和工作门上安装玻璃观察窗镀铝锌板认为整体结构牢固,与墙板结合良好。
2镀锌板、彩钢板框架连接:由于采用了镀锌板,彩钢板的高度已经达到3150毫米为了使镀锌板和彩涂板达到更安全、更精细的目的,我们设计了框架结构采用40mm×40mm方钢管从内侧穿过复合板,水平、垂直连接成整体共5组。
三。镀锌板与彩涂板的照明连接:采用顶边灯与腰边灯相结合的方法这种结构使室内光线柔和、均匀、明亮,室内光线强度达800lum以上灯管采用飞利浦灯管照明镇流器是一种性能稳定、使用寿命长的特殊镇流器。
四镀锌板和彩涂板的净化环节:采用双层外滤结构,滤棉能有效过滤直径大于10μm的粉尘颗粒,精密过滤层为sp-600超厚多层结构滤棉可有效过滤直径大于4μM的粉尘颗粒,整个过滤环节粉尘体积大,阻力小,使用寿命长,过滤效率达98%以上。
5个根据镀锌板、彩钢板房风量要求,风量为18000m3/h,镀锌板、彩钢板采用一套正压送排风环节送风环节配置2台3KW正压风机,采用镀锌板成型,风量大,耐温性好全部由特种风机厂生产。
6外部加热环节:采用远红外电加热装置主要包括远红外发生器、不锈钢反射镜、电线、线槽等,该镀锌板、彩涂板共设有24套加热环节考虑到实际使用情况,每套采用0.8kw远红外发生器,采用三种方式控制,更安全控制和使用功率30kW,相应使用不锈钢散热器热交换率在95%以上。
7号汽车镀锌板和彩涂板的环保处理:采用空气过滤碳吸附过滤装置和两块玻璃纤维过滤垫进行烤漆处理环保型空气过滤碳过滤环节采用两块玻璃纤维滤布,先对漆雾进行一次过滤和二次过滤,再进行空气过滤碳层有效吸附器,废气中不含苯、甲苯、二甲苯等有害物质,空气过滤碳具有很强的吸附,易过滤漆雾,易清洗,保证通风效果由于漆雾的空气通过空气过滤炭时与表面混合,形成多级净化工艺,提高了汽车烤漆的净化效果,达到去除漆雾,保证烤漆环境不受污染的目的确保汽车尾气排放达到国家标准
8个镀锌板和彩涂板的控制环节:①电气控制方案力求经济、适用、安全可靠②一次电源由用户提供(即车间电源柜送电

1. Galvanized plate, color coated plate link: adopt assembled EPS socket color steel insulation plate, the thickness of the wall panel is 50mm, the outer layer is color coated plate, the middle is filled with EPS insulation material, PU foaming continuous molding, the inner and outer plates and insulation materials are pressed as a whole. All the wall panels are made of 50 mm thick EPS sandwich color steel plate, and the top plate is assembled with color steel insulation plate. The outer diameter of the galvanized plate room is designed to be (L × w × h) mm: 7000 × 4000 × 3150, and the inner diameter of the equipment is (l × w × h) mm: 6900 × 3900 × 2600. A set of gate is set at the front end of the room, and the gate size (w × h) mm: 2800 × 2500. The side of the room is set with a set of gate A set of safety door, the size (width × height) of which is mm: 750 × 1800, the material is the same as the side plate, and the safety door is equipped with pressure protection device to ensure the safety of use. When the pressure in the room is too large, the safety door will automatically open and release the pressure, and can be evacuated and passed. Glass observation windows are installed on the door and the working door. Aluminized zinc plate thinks that the overall structure is firm and perfectly combined with the wall plate.

2. Galvanized sheet, color coated sheet frame link: because of the galvanized sheet, the height of color coated sheet has reached 3150mm. In order to make the galvanized sheet and color coated sheet achieve the purpose of more safety and refinement, we designed the frame structure. 40mm × 40mm square steel pipe is used to pass through the composite plate from the inside, and is connected horizontally and vertically to form a whole. A total of 5 groups.
3. Lighting link of galvanized sheet and color coated sheet: adopt the method of combining the top side and waist side lights. This structure makes the light in the room soft, uniform and bright, and the light intensity in the room is more than 800lum. The lighting tube adopts Philips light tube for lighting. The ballast is a special ballast with stable performance and long service life.
4. Purification links of galvanized plate and color coated plate: adopt double external filter structure, filter cotton can effectively filter dust particles with diameter greater than 10 μ m, and precise filter layer is sp-600 ultra thick filter cotton with multi-layer structure, which can effectively filter dust particles with diameter greater than 4 μ M. the whole filter link has large dust volume, small resistance, long service life and filtering efficiency of over 98%.
5. According to the requirements of the air volume in the galvanized sheet and color coated sheet room, the air volume is 18000m3 / h. The galvanized sheet and color coated sheet adopt a set of positive pressure air supply and exhaust links. The air supply link is equipped with two 3KW positive pressure fans, which are molded by galvanized sheet, with large air volume and good temperature resistance. All of them are manufactured by special fan factory.
6. External heating link: far infrared electric heating device is used. It mainly includes far-infrared generator, stainless steel reflector, wire and trunking, etc. This galvanized sheet and color coated sheet are equipped with a total of 24 sets of heating links. Considering the actual situation of use, each set adopts a 0.8kw far-infrared generator, which is controlled in three ways for more safe control and use. The power is 30kW, and the heat radiator made of stainless steel is used correspondingly. The heat exchange rate is over 95%.
7. Environmental protection treatment of automobile galvanized plate and color coated plate: air filtration carbon adsorption filtration device and two glass fiber filter mats are used for paint baking treatment. Two glass fiber filter mats in environmental protection type air filtration carbon filtration link are used for one-time filtration and two-time filtration of paint mist first, and then air filtration carbon layer effective adsorber is free of benzene, toluene, xylene and other harmful substances in exhaust gas 。 The air filter carbon has strong adsorption, is easy to filter paint mist, is easy to clean, and ensures ventilation effect. As the air of paint mist is mixed with the surface when passing through the air filter carbon, a multi-level purification process is formed, which improves the purification effect of car paint baking, so as to achieve the removal of paint mist and ensure that the paint baking environment is not polluted, so as to ensure that the emission of car exhaust meets the national standard 。
