如何安装固定彩钢板?

如何安装固定彩钢板?

天物彩板专注彩板行业16年——河南彩钢卷,彩涂板最新价格表咨询请拨打网站上方电话免费咨询

1、彩涂板厂家 彩钢板的安装和固定有两种方式:穿墙式和暗装式。通过固定是彩钢板在屋顶和墙壁上安装最常用的方式,即用自攻螺钉或铆钉将彩钢

板固定在支架上。通过固定分为波峰固定、波谷固定或它们的组合。暗扣暗固定是将与暗扣彩钢板配套的专用扣先固定在支架上,彩钢板主筋与暗扣中心筋成齿的固定方法,一般用于屋面板的安装。

河南彩钢卷,彩涂板最新价格表咨询_天物彩板


2、彩涂板厂家 彩钢板的侧面和端部搭接。每块钢板安装时,应将搭接边准确地放在前一块彩钢板上,用前一块钢板夹紧,直至钢板两端固定。一种简单有效的方法是用钳子夹住重叠的钢板。钢板沿纵向放置时,用钳子夹住钢板的一端,特别是上端,保证钢板的一端就位,一端的搭接也在正确的位置,以固定钢板。在固定过程中,夹钳应始终沿纵向夹住钢板。在安装下一块钢板之前,每个钢板必须完全固定。固定必须从钢板的中心开始,然后向两边延伸,最后固定钢板的搭接边。对于端部搭接,由于顶、墙型钢板采用连续加工方式,可根据运输条件限制的长度提供钢板。一般不需要搭接,钢板长度足以满足屋面铺设的需要。

3、 彩涂板厂家自攻螺钉的选择。应根据结构的使用寿命选择固定螺钉和固定件,并特别注意包层材料的使用寿命是否与规定的固定件的使用寿命一致。同时,钢檩条的厚度不得超过螺杆的自钻能力。目前可用的螺钉可以有塑料头、不锈钢盖或涂有特殊耐用的保护涂层。另外,除用于卡扣固定的螺钉外,其余螺钉均设有防水垫圈,照明面板及特殊风压均设有相应的专用垫圈。

1、 There are two ways to install and fix the color steel plate: through type and concealed type. Through fixing is the most common way to install the color steel plate on the roof and wall, that is, to fix the color plate on the support with self tapping screws or rivets. Through fixing is divided into wave crest fixing, wave trough fixing or their combination. Concealed fixation of concealed buckle is the fixation method that the special buckle matched with the concealed buckle color steel plate is fixed on the support first, and the main rib of the color plate and the central rib of the concealed buckle are toothed, which is generally used for the installation of roof panel. 2、 The side of color steel plate And end lap. When installing each steel plate, the edge lap shall be accurately placed on the previous color steel plate and clamped with the previous steel plate until both ends of the steel plate are fixed. A simple and effective method is to clamp the overlapped steel plates with a pair of pliers. When the steel plate is placed along the longitudinal direction, its end, especially the upper end, shall be clamped by pliers to ensure that one end of the steel plate is in place, and the overlap at one end is also in the correct position, so as to fix the steel plate. During the fixing process, the clamp shall always clamp the steel plate in the longitudinal direction. Before installing the next steel plate, each steel plate must be completely fixed. The fixing must start from the center of the steel plate, then extend to both sides, and finally fix the lap edge of the steel plate. For end lapping, since roof and wall profile plates are made by continuous processing method, steel plates can be supplied according to the length limited by transportation conditions. Generally, no lapping is required, and the steel plate length is enough to meet the needs of roof laying. 3、 Selection of self tapping screws. The fixing screw should be selected The fixed parts shall be selected according to the service life of the structure, and special attention shall be paid to whether the service life of the cladding material is consistent with that of the specified fixed parts. At the same time, the thickness of steel purlin shall not exceed the self drilling capacity of screw. The screws currently available can have plastic heads, stainless steel covers or be coated with a special durable protective coating. In addition, in addition to the screws for snap fixing, all other screws are provided with waterproof washers, and the corresponding special washers are provided for the lighting panel and special wind pressure.
