彩钢板车棚的设计应该考虑哪些?

彩钢板车棚的设计应该考虑哪些?

天物彩板专注彩涂板行业17年——更多彩钢板车棚的设计_彩钢板厂房批发原材料_天物压型彩钢板请拨打网站上方电话咨询

在目前的车棚领域中,彩钢板车棚是发展最快的类型,这种车棚也受到了时代的极大欢迎,促进了车棚的发展。然而,具体而言,无论是哪种建筑,其设计都需要遵循和考虑一些方面,而彩钢板车棚也不例外。这种建筑的具体设计应该考虑什么?

tu (21)
从现状来看,彩钢棚的设计主要包括:初始状态分析;负荷状态分析;主要结构构件尺寸的确定和支撑结构的有限元分析;连接设计:包括螺栓、焊缝和二次部件的尺寸;裁剪设计等。这些也构成了彩钢棚设计的主要元素。此外,在设计入口时需要考虑建筑物的预张力和张拉模式;如何根据控制负荷确定隔板尺寸和电缆布置;如何避免膜表面形状及其固定件出现积水;如何处理关键节点的设计,避免应力集中;膜材料的运输等。
这些构成了当前彩钢板棚设计中需要考虑的一些主要因素,在充分考虑这些因素的情况下,将更有利于棚的整体建设。

In the current car shed field, the color steel plate car shed is the fastest developing type, and this kind of car shed has also been greatly welcomed by the times and promoted the development of the car shed. However, specifically, no matter what kind of building, its design needs to follow and consider some aspects, and the color steel plate car shed is no exception. What should be considered in the specific design of this kind of building?

From the current situation, the design of color steel shed mainly includes: initial state analysis; Load state analysis; The determination of the size of the main structural members and the finite element analysis of the supporting structure; Connection design: including the dimensions of bolts, welds and secondary components; Tailoring design, etc. These also constitute the main elements of color steel shed design. In addition, the pre tension and tensioning mode of the building need to be considered when designing the entry; How to determine the size of diaphragm and the arrangement of cable according to the control load; How to avoid ponding in the shape of membrane surface and its fixings; How to deal with the design of key nodes to avoid stress concentration; Transportation of membrane materials, etc.
These constitute some main factors that need to be considered in the current color steel plate shed design, and it is in the case of perfect consideration of these factors that it will be more helpful for the overall construction of the shed.
