1. Galvanized plate, color coated plate link: adopt assembled EPS socket color steel insulation plate, the thickness of the wall panel is 50mm, the outer layer is color coated plate, the middle is filled with EPS insulation material, PU foaming continuous
molding, the inner and outer plates and insulation materials are pressed as a whole. All the wall panels are made of 50 mm thick EPS sandwich color steel plate, and the top plate is assembled with color steel insulation plate. The outer diameter of
the galvanized plate room is designed to be (L × w × h) mm: 7000 × 4000 × 3150, and the inner diameter of the equipment is (l × w × h) mm: 6900 × 3900 × 2600. A set of gate is set at the front end of the room, and the gate size (w × h) mm: 2800 ×
2500. The side of the room is set with a set of gate A set of safety door, the size (width × height) of which is mm: 750 × 1800, the material is the same as the side plate, and the safety door is equipped with pressure protection device to ensure
the safety of use. When the pressure in the room is too large, the safety door will automatically open and release the pressure, and can be evacuated and passed. Glass observation windows are installed on the door and the working door. Aluminized
zinc plate thinks that the overall structure is firm and perfectly combined with the wall plate.
2. Galvanized sheet, color coated sheet frame link: because of the galvanized sheet, the height of color coated sheet has reached 3150mm. In order to make the galvanized sheet and color coated sheet achieve the purpose of more safety and refinement, we
designed the frame structure. 40mm × 40mm square steel pipe is used to pass through the composite plate from the inside, and is connected horizontally and vertically to form a whole. A total of 5 groups.
3. Lighting link of galvanized sheet and
color coated sheet: adopt the method of combining the top side and waist side lights. This structure makes the light in the room soft, uniform and bright, and the light intensity in the room is more than 800lum. The lighting tube adopts Philips light
tube for lighting. The ballast is a special ballast with stable performance and long service life.
4. Purification links of galvanized plate and color coated plate: adopt double external filter structure, filter cotton can effectively filter dust
particles with diameter greater than 10 μ m, and precise filter layer is sp-600 ultra thick filter cotton with multi-layer structure, which can effectively filter dust particles with diameter greater than 4 μ M. the whole filter link has large dust volume,
small resistance, long service life and filtering efficiency of over 98%.
5. According to the requirements of the air volume in the galvanized sheet and color coated sheet room, the air volume is 18000m3 / h. The galvanized sheet and color coated
sheet adopt a set of positive pressure air supply and exhaust links. The air supply link is equipped with two 3KW positive pressure fans, which are molded by galvanized sheet, with large air volume and good temperature resistance. All of them are manufactured
by special fan factory.
6. External heating link: far infrared electric heating device is used. It mainly includes far-infrared generator, stainless steel reflector, wire and trunking, etc. This galvanized sheet and color coated sheet are equipped
with a total of 24 sets of heating links. Considering the actual situation of use, each set adopts a 0.8kw far-infrared generator, which is controlled in three ways for more safe control and use. The power is 30kW, and the heat radiator made of stainless
steel is used correspondingly. The heat exchange rate is over 95%.
7. Environmental protection treatment of automobile galvanized plate and color coated plate: air filtration carbon adsorption filtration device and two glass fiber filter mats are
used for paint baking treatment. Two glass fiber filter mats in environmental protection type air filtration carbon filtration link are used for one-time filtration and two-time filtration of paint mist first, and then air filtration carbon layer effective
adsorber is free of benzene, toluene, xylene and other harmful substances in exhaust gas 。 The air filter carbon has strong adsorption, is easy to filter paint mist, is easy to clean, and ensures ventilation effect. As the air of paint mist is mixed with
the surface when passing through the air filter carbon, a multi-level purification process is formed, which improves the purification effect of car paint baking, so as to achieve the removal of paint mist and ensure that the paint baking environment is
not polluted, so as to ensure that the emission of car exhaust meets the national standard 。
