股高为51mm高的镀锌彩钢楼承板有哪些?

返回列表 来源: 发布日期: 2020.03.29

股高为51mm高的镀锌彩钢楼承板有哪些?

天物彩板专注彩板行业16年——为工程定制提供彩钢板解决方案,关于楼承板请拨打网站上方电话咨询

一、开口型楼承板

1、YX51-226-678楼承板,可称作YX51-226-678压型钢板、YX51-226-678钢承板、YX51-226-678开口楼承板,由三个波组成,每个波距为226mm,有效宽度为678mm,采用的是1000mm展开宽度、0.7-1.6mm厚的冷轧热镀锌钢板冷压成型的。YX51-226-678是比较少见的一种楼承板型号。

2、硅改性聚酯彩板YX51-240-720楼承板,也可以称作YX51-240-720压型钢板、YX51-240-720钢承板、YX51-240-720开口楼承板,或称HG-240型楼承板。YX51-240-720板型数据:肋高51mm,波宽240mm,有效宽度720mm。表面带压痕,加劲肋。

 3、YX51-246-750楼承板,又称YX51-246-750压型钢板、YX51-246-750钢承板、YX51-246-750开口楼承板、YX51-246-750楼层板,是开口楼承板的一款型号,波高51mm,由三个波组成,有效宽度为750mm,展开宽度为1000mm,采用冷轧热镀锌钢板冷压成型的。

 4、硅改性聚酯彩板YX51-246-760楼承板,又称YX51-246-760压型钢板、YX51-246-760开口楼承板、YX51-246-760钢承板、YX51-246-760楼层板等,是一款开口楼承板型号,采用展开宽度为1000mm的冷轧热镀锌钢板冷压成型,成型后的压型钢板有效宽度为760mm。

 5、YX51-250-750楼承板,也可以称作YX51-250-750压型钢板、YX51-250-750钢承板、YX51-250-750开口楼承板,是比较常见和拥有好多年历硅改性聚酯彩板史的老板型了。在51波高楼承板中,750楼承板应该是比较早的一款板型,波高是51mm,波矩250mm,有效宽度为750mm,采用1000mm宽度的镀锌板辊压成型。

One, open-mouth floor bearing plate

1, yx51-226-678 floor bearing plate, can be called yx51-226-678 pressure plate, yx51-226-678 steel bearing plate, yx51-226-678 steel bearing plate, yx51-226-678 open floor bearing plate, composed of three waves, each wave distance is 226mm, the effective width is 678mm, using 1000mm expansion width, 0.7-1.6mm thick cold rolled hot galvanized steel cold pressing. Yx51-226-678 is a rare type of floor plate.
2. Yx51-240-720 floor bearing plate, also known as yx51-240-720 pressure plate, yx51-240-720 steel bearing plate, yx51-240-720 steel bearing plate, yx51-240-720 open floor bearing plate, or hg-240 floor bearing plate. Yx51-240-720 plate type data: rib height 51mm, wave width 240mm, effective width 720mm. Surface with indentation, stiffener.
Yx51-246-750 floor bearing plate, also known as yx51-246-750 pressure plate, yx51-246-750 steel bearing plate, yx51-246-750 steel bearing plate, yx51-246-750 open floor bearing plate, yx51-246-750 floor plate, is a model of open floor bearing plate, wave height of 51mm, composed of three waves, effective width of 750mm, the width of 1000mm, using cold rolled hot galvanized steel cold pressing.
Yx51-246-760 floor bearing plate, also known as yx51-246-760 pressure plate, yx51-246-760 open floor bearing plate, yx51-246-760 steel bearing plate, yx51-246-760 floor plate, yx51-246-760 steel bearing plate, yx51-246-760 floor plate, is a type of open floor bearing plate, the width of the use of 1000mm of cold rolled hot galvanized steel cold pressing forming, forming the effective width of the pressure plate is 760mm.
5, yx51-250-750 floor bearing plate, also known as yx51-250-750 pressure plate, yx51-250-750 steel bearing plate, yx51-250-750 steel bearing plate, yx51-250-750 open floor bearing plate, is more common and has many years of history of the boss type. In the 51 wave tall building bearing plate, 750 floor bearing plate should be a relatively early plate type, wave height is 51mm, wave moment 250mm, effective width is 750mm, using 1000mm width galvanized sheet roller press molding.
