1、 The correct laying method of color steel tile is as follows:
1. Overlapping type (suitable for roof with length ≤ 15m)
2. Staggered type (suitable for roof with length ≥ 15m)
2、 Correct use method of special nail for color steel tile:
1. The special nail for color steel tile must be hit in the
middle of tile bone to have waterproof effect.
2. The fixation interval of color steel tile is 50cm ~ 100cm (4 pieces / m2).
3. The special nail must be driven from the lower end of the tile to the direction of the roof in order to have a
beautiful, sealed and neat effect
3、 Color steel tile installation sealing strip ridge tile eaves cover:
1. Divide the color steel tile seal into two parts, press it on the roof according to the tile shape, and fix it with special nails.
2. At the junction of the side tiles of the colored steel tiles, the back tiles are directly covered with cement after sealing treatment, and the bottom of the back tiles are closed with a small tile stop.
3. The lower end of the color steel
tile is directly installed at the eaves, and the eaves cover is fixed with screws.
4. At the junction of the back tile, the control interface is trimmed with scissors, and then overlapped and sealed with glass glue.
