如何辨别彩涂板牌号?你认识几个呢?

返回列表 来源: 发布日期: 2021.05.25

如何辨别彩涂板牌号?你认识几个呢?

为了识别彩涂板的品牌,我们需要知道彩涂板的命名方法。彩涂板品牌的命名由彩涂代号、基板特征代号和基板类型代号组成。加号“+”用于连接基板特征代码和基板类型代码。
色码:用汉语拼音第一个字母“t”表示。

3.彩板厂家价格 (1)4
基板特征代码:
a) 冷成型用钢
第一部分是字母“d”,代表冷成型钢板;彩涂板第二部分是字母“C”,意思是轧制条件是冷轧;第三部分是两位序列号,即01、03和04。
第一、二部分与电镀基板相同,第三部分为两位序列号,分别为51、52、53、54;第四部分是字母“d”,代表热镀。
b) 结构钢
它由四个部分组成。第一部分是字母“s”,代表结构钢;第二部分为三位数字,表示规定的最小屈服强度(MPA),即250、280、300、320、350和550;第三部分为字母“g”,代表hea治疗;第四部分是字母“d”,代表热镀。
基板类型代码
“Z”代表热镀锌基板,“ZF”代表热镀锌铁合金基板,“AZ”代表热镀锌铝锌合金基板,“Za”代表热镀锌铝合金基板,“Ze”代表电镀锌基板。

In order to identify the color coated plate brand, we need to know the naming method of color coated plate. The naming of color coated plate brand consists of color coated code, substrate characteristic code and substrate type code. The plus sign "+" is used to connect the substrate characteristic code and substrate type code.

Color code: it is indicated by the first letter "t" of Chinese pinyin.
Substrate characteristic code:
a) Steel for cold forming
The first part is the letter "d", which stands for the cold forming steel plate; The second part is the letter "C", which means that the rolling condition is cold rolling; The third part is two digit serial numbers, namely 01, 03 and 04.
The first and second parts are the same as the electroplating substrate, and the third part is two digit serial numbers, namely 51, 52, 53 and 54; The fourth part is the letter "d", which stands for hot plating.
b) Structural steel
It is composed of four parts. The first part is the letter "s", which stands for structural steel; The second part is a three digit number, representing the specified minimum yield strength (in MPA), namely 250, 280, 300, 320, 350 and 550; The third part is the letter "g", which stands for hea treatment; The fourth part is the letter "d", which stands for hot plating.
Base plate type code
"Z" stands for hot dip galvanized substrate, "ZF" stands for hot dip galvanized ferroalloy substrate, "AZ" stands for hot dip galvanized aluminum zinc alloy substrate, "Za" stands for hot dip galvanized aluminum alloy substrate, "Ze" stands for electro galvanized substrate.
